Model Name |
ATS2A7 |
ATS2A10 |
ATS7 |
ATS10 |
|
Display |
7" TFT LCD
800*480
350cd |
10.2" TFT LCD
800*480
350cd |
7" TFT LCD
(260,000 Color)
800*480
300cd |
10.2" TFT LCD
(260,000 Color)
800*480
350cd |
|
CPU |
S5PC100 (ARM CORTEX A8, 800MHz)
|
S3C2450(533MHz) |
|
Memory |
SDRAM 256MB + NAND Flash 256MB |
Mobile DDR(266MHz) 128MB + NAND Flash 128MB |
|
Serial Port |
RS232 2 Ports, RS485 1 Port |
2 RS-232C, 1 RS-485/232C Option |
|
USB |
2 Ports |
USB 2.0 1Port(High Spped : 480 Mbps), Host : USB 1.1 Port(Full
Speed) |
|
Audio |
1 Port (Stereo Earphone Jack) |
Internal Speaker(0.8W),
Audio Out(3.5 Audio Jack) |
|
Ethernet |
1 Port (10/100BASE-T) |
100Base-T LAN 1 Port |
|
SD Card |
1 Port |
SD Card 1 slot (4 Giga supported) |
|
OS |
Windows CE 6.0 |
Windows Embedded CE 6.0 |
|
Voltage |
DC 12V~24V |
DC12V ~ 24V |
|
Power consumption |
8.8W |
6W |
10W |
|
Max Current |
733mA |
733mA |
500mA |
800mA |
|
Size(mm) |
210(H)*135(V)*35(D) |
284(H)*163(V)*56(D) |
222(H)*152(V)*56(D) |
284(H)*163(V)*56(D) |
|
Weight |
650g |
1040g |
650g |
1040g |
|
Waterproof |
IP65 |
- |
|
Operating Temperature |
0~70˚C |
0 ~ 70˚C |
|
|
|
|
|
|
 |
|
|
|
|
