Model Name |
ATP12-S |
ATP2B15-S |
ATP15-S |
ATP15P-S |
ATP17-S |
ATP19-S |
|
Components |
Autobase SCADA Local Server OEM
+
ATP12
|
Autobase SCADA Local Server OEM
+
ATP2B15
|
Autobase SCADA Local Server OEM
+
ATP15
|
Autobase SCADA Local Server OEM
+
ATP15P |
Autobase SCADA Local Server OEM
+
ATP17 |
Autobase SCADA Local Server OEM
+
ATP19 |
|
Display |
12.1 inch
SVGA(800*600) |
15 inch
XGA(1024*768) |
15 inch
XGA(1024*768) |
15 inch
XGA(1024*768) |
17 inch
SXGA(1280*1024) |
19 inch
SXGA(1280*1024) |
|
CPU |
Intel ATOM D525 Dual Core 1.8 GHz (FSB:800 MHz) |
Intel ATOM N270 1.6 GHz (FSB:533/667 MHz) |
|
Touch Controller |
PenMount USB controller |
|
Main Board |
Support Intel ICH8M chipset,
ATOM
|
Support Intel 945GSE,ATOM (FSB:533/667 MHz) |
|
Main Memory |
2GB DDR3(1066Mhz/PC8500) |
2GB DDR2(667Mhz/PC5300) |
|
Storage |
SSD 120GB(Max Read:500MB/s, Write:400MB/s) |
|
VGA |
Intel GMA 3150 Graphics Dual Channel 128MB (LVDS/Analog) |
Intel GMA 950 Graphics Dual Channel 128MB (LVDS/Analog) |
|
Audio |
Mic-in, Line-out |
|
Ethernet |
2 Ports (Gigabit LAN) |
|
Serial Port |
3 Ports (RS-232C 3Ports) |
4 Ports (RS-232C 3Ports, RS-232C/422 Optionanl 1Port) |
|
USB |
4 Ports |
|
Keyboard/Mouse |
USB type |
Mouse 1 port, KeyBoard 1 Port (PS/2) |
|
CD-ROM |
No |
|
OS |
Windows Embedded Standard 7 Included |
|
Utility |
Rescue ( Recovery Tools Included ) |
|
Voltage |
DC 12V(50~60Hz) |
AC 115~230V(50~60Hz) |
|
Power |
38W(Max 60W) |
43W~55W |
|
Waterproof |
X |
X
|
X
|
Front(IP65) |
X |
X |
|
|
|
|
|
|
|
Option |
|
|
SSD 120GB |
Upgrade SSD 120GB with SSD 250GB ( Intel ) |
|
HDD 500GB |
Replace SSD 120GB with HDD 500GB ( SATA2 / 7200 rpm / 16M ) |
|
LCD Stand |
PS-20S, ( Prime Direct ) |
 |
|
|
|
|
|
|
