Autobase SCADA X
Overture of Cross Platform: Windows X Linux
Make your cross platfrom solution for Windows / Linux with one single project.
📋 About SCADA X
Cross Platform
Aiming for Windows X Linux multi platform
with one single project.
High Compatibility
Available with previous Autobase SCADA 10 project
without additional modification.
Easy to Use
Designed beginner friendly for the users
who don't know anything about Linux Ubuntu.
Flexible Range
Manageable for various scale of field
with one single S/W.
🎯 What is AUTOBASE SCADA X ?
AUTOBASE SCADA X is a program which can be run on both Windows and Linux, aiming for multi platform solution.
With a single software, we are pursuing to make free and flexibile choice to users from hardwares and operating systems.
Let the same experience begin in new environment with our technical history over 30 years.
🚀 Main Features
Illustration generated by AI for conceptual purposes.
All product names and logos are trademarks of their respective owners.
🌏 Platforms
✔ Available Platforms
🕑 Platforms On Test
💡 Features above may be changed in development process.
📌 * User privilege may need to be set to enable KeyLock Check / Serial Port Communication / Creating Files.
🏭 Function Comparison
| Function | SCADA | SCADA-Lite | SCADA X | SCADA CE | |
|---|---|---|---|---|---|
| v10.3.7 | v10.3.7 | v1.0.0.2 | v3.6.5 | ||
| Monitoring | Maximum number of tags | Unlimited | 512 Tags | * 512 Tags recommended | 250 Tags recommended |
| Graphic / Tag Monitoring | O | O | O | O | |
| Detail / Trend / Data View | O | O | O | O | |
| Alarm Event / Sound / File | O | O | O | O | |
| Log File | O | O | O | O | |
| Flow Watch | O | O | X | X | |
| Graphic | Transparency | O | O | O | X |
| Object Rotation | O | O | O | X | |
| Gradient Brush | O | O | O | X | |
| Multiple MDI | O | O | X | X | |
| SVG (Vector Image) | O | O | O | X | |
| Analog Gauge | O | O | O | X | |
| Donut Chart | O | O | O | X | |
| Real-time Test Graph | O | O | X | X | |
| XY Graph | O | O | O | X | |
| TreeView | O | O | X | O | |
| TabControl | O | O | X | O | |
| VLC | O | X | X | X | |
| WebView | O | X | X | X | |
| Control | Schedules | O | O | O | O |
| Script Run/Editor | O | O | O | O | |
| Demand Control | O | O | X | X | |
| Communication | Network Memory Server | O | O | O | O |
| DDE Tag | O | O | X | O | |
| Modbus Slave | O | O | O | O | |
| SMS Manager | O | O | O | O | |
| App push Alarm | X | X | O | X | |
| Line Printer | O | O | X | X | |
| Line Duplex | O | O | O | X | |
| OPC UA Server / Client | O | O | O | X | |
| API - JSON / HTTP Header | O | X | O | X | |
| Web Server | O | X | X | X | |
| Report | Autobase / Excel Report | O | X | X | X |
| Database | OnOffList | O | X | O | X |
| Database | O | X | O | X | |
| DataGrid | O | X | X | X | |
| MilliData (Save data by second) | O | X | O | X | |
| Updated Date: 2026-02-25 | |||||
* Recommendation for ATL-1B07C / ATL-1B15C H/W.
( Recommended number of Tags for SCADA X can be different depending on H/W performance. )
❓ Please contact us if you need more detailed descriptions about functions of ScadaX.
💡 Features above may be changed in development process.
